Optical

• Light Source

  180 LEDs (36 red, 36 green, 36 blue, 36 amber, 36 lime) 2.5 W to 3.5, (725 mA)

• Color Temperature (range)

  2800 to 6500 K

• CRI (3200K)

  90

• Beam Angle (Horizontal)

  111.4°

• Field Angle (Horizontal)

  151.8°

• Beam Angle (Vertical)

  76.7°

• Field Angle (Vertical)

  134.4°

• Lumens

  19,575

• Illuminance (total)

  280 lux @ 5 m

• PWM Frequency

  600, 1200, 2000, 4000, 6000, 25,000 Hz







Dynamic Effects

• Dimmer

  Electronic

• Shutter/Strobe

  Electronic

• Strobe Rate

  0 to 29 Hz

• Standalone Color Mixing

  Yes

• Color Temperature Presets

  Yes

• Dim Modes

  4

• Dim Curves

  4

• Built-in Automated Programs

  Yes

• Customizable Programs

  No

• Recall Custom Programs

  No



Connections

• Power Connection

  Edison (Local) plug to Seetronic Powerkon IP65

• Power Input

  Seetronic Powerkon IP65

• Power Output

  Seetronic Powerkon IP65

• Data Connectors

  5-pin XLR

• Cable Length (power)

  5 ft (1.5 m)
