General Specifications

• Faders: 26 x 100mm touch-sensitive, motorised
• Screens: 2 x 17” LCD high – brightness, high – resolution touch screens
• Input Channels: 128
• Busses: Up to 64 Aux / Group busses with full processing Mono / Stereo / LCR / LCRS / 5.1
• Matrix: Up to 24 Input / 24 Outputs with full processing
• Control Groups: Up to 24, selectable for VCA-style, Moving fader, Mute Group
• Internal FX: Up to 24 stereo effects comprising floating point reverbs and delay/chorus/pitch/enhancer
• Spice Rack: 8  mono / 4 stereo Rack Slots
• Mustard Proc: 36 Processing Strips
• Nodal Proc: 64 Nodal Processors
• Local I/O: 8 x 32bit mic/line I/O, 8 x AES I/O
• MADI interface: 6 x interfaces @ 48kHz,  3 interfaces @ 96kHz, BNC connectivity
• Optocore Interface: Optional (dual loop available)
• Sampling rates: 48kHz / 96kHz
• GPI/GPO: 16
• DMI: 2 x DiGiCo Multichannel Interface
• Waves: Optional
• Ext Sync: Wordclock, AES, MADI, Optocore
• Quantum 326 Dimensions: 1124mm (w) x 805mm (d) x 482mm (h)
• Quantum 326 Weight: 52Kg  (150Kg with flightcase)
• Quantum 326 Flightcase: 1251mm (w) x 646mm (d) x 1151mm (h)
• Power Requirements 100V-240V, 50-60Hz, 295VA
