CODA AUDIO – OMNIO 5
CODA AUDIO – OMNIO 5
Mixrack 48 entrées, 24 sorties
Informations complémentaires
| Poids | 53,3 kg |
|---|
Specification
| Type | Omnidirectional 2-way Installation System |
|---|---|
| Application | Superior quality 360° horizontal dispersion |
| Frequency response | 75 Hz – 21 kHz (-6 dB) |
| Power handling (AES) | 150 W |
| Program power | 300 W |
| Peak power | 600 W |
| Sensitivity | 92 dB |
| Max. SPL peak | 118 dB* |
| Dispersion horizontal | 360° |
| Dispersion vertical | 120° (60° in half space) |
| Components | |
| Low frequency | 5″ woofer, 1.5″ (38 mm) voice coil, 150 W (AES) |
| High frequency | 1″ coaxially mounted driver, 1″ (25.4 mm) voice coil, 30 W (AES) |
| Crossover point | 1140 Hz passive |
| Nominal imepdance | 16 Ω (1+/1-) |
| Cabinets per channel | 6** |
| 70V version (optional) | Switchable: 150W / 75W / 37.5W / 19W |
| Input connectors | 3 m sealed cable |
| Enclosure material | Solid aluminium |
| Finish | Two part paint base/clear, RAL7021 (all RAL colours available on request) |
| IP rating (IEC 60529): | IP56 |
| Weather protection options: | MG1 by default (direct cable) |
| Dimensions (WxHxD) | 164 x 393 x 164 mm / 6.33″ x 15.47″ x 6.33″ (incl. hardware) Diameter: 160 mm / 6.3″ |
| Net weight | 8 kg / 17.64 lbs |
